Input power:100-240V 50/60 Hz

LAMP SOURCE
Discharge lamp with a short arc burner in a reflector system
-Type: MSD R17 350W
-Output Lamp power: 600W
-Color temperature: 8,500 K
-Average life: 2,000 h

OPTICS
3-lens optical group combinationFocus: electronic
Light output at 10 meters: 160000 lux

COLOR SYSTEM
Interchangeable color wheel with 14 colors + open

EFFECTS SECTION
Interchangeable gobo wheel with 17 fixed gobos + open High speed shake effect
16-face rotatingprism Frost filter
Mechanical shutter and adjustable speed strobeeffect Mechanical dimmer

CONTROL AND PROGRAMMING
16/20 DMX 512 control channels
Display: LCD display
Pan/Tilt Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 3 PIN output

MOVING BODY
Travel: -PAN = 540° - TILT = 210°

ELECTRONICS Function reset from the lighting desk ON/OFF lamp control from the lighting desk "AUTOTEST" function from menu Electronic monitoring with status error

SAFETY DEVICES
Bipolar circuit breaker with thermal protection. Automatic break in power supply in case of overheating or failed operation of cooling system.
Forced ventilation with axial fans.

WEIGHT
32.5 Kg
